Features
- Support up to 576 x 10 GE ports per switch, forwarding rates up to 2,880 Mpps, scalable with SVF 2.0 and CSS technologies to maximum switching capacity up to 3.84 Tbit/s in a fully configured switch
- Huawei’s Packet Conservation Algorithm for Internet (iPCA) on ENP agile cards uses marks added to service packets to actively monitor network quality, detecting temporary interruptions and faulty ports within seconds
- Available AC boards provide native wireless support, fully integrated with the NMS for managing up to 4K APs and 32K users
- Unified user management supports 802.1X, MAC, and Portal authentication in a simple visual user interface
- SVF 2.0 simplifies management by virtualizing the network — fixed switches into Line Processing Units (LPU) and APs into ports
Technical Specifications
| Network | Wired LAN |
| Switching Capacity | 3.84 Tbit Or s |
| Forwarding Performance | 2,880 Mpps |
| Service Slot | 12 |
| Redundancy Design | Supervisors, Power Modules, CMUs, And Fan Trays |
| Wireless Management | Native AC, Wired And Wireless Convergence |
| User Management | Unified Management Of Wired And Wireless Users |
| SVF 2.0 | Up To 256 Clients (Access Switches) |
| Routing | IPv4 Static Routes, RIP, OSPF, IS To IS, And BGP4 |
| Buffer Capacity | Up To 200 ms Per Port |
| Interoperability | VLAN Based Spanning Tree (VBST) |
| Switching Capacity | 3.84 Tbps Or 5.12 Tbps |
| Forwarding Performance | 1344 Mpps Or 3360 Mpps |
