Technical Specifications
| Transmission Distance | Max 984.25 feet (300 m) |
| Communication Methods | Ethernet, Optical fiber, Wi-Fi, 4G, 5G (Optical) |
| Industrial Communication Interface | RS458 |
| Communication with Sensor | Zigbee: 1.4 GHz IEEE 802.15.4 |
| IP Grade | IP66 |
| Shell Material | Cast aluminum |
| Maximum Number of Supported Sensors | 60 pcs |
| Maximum Channels (Optional) | 8 channels, 16 channels, 24 channels |
| Channel Number | 24 channels |
| Sensor Integrated | IEPE acceleration sensor, High/low frequency and dual acceleration acquisition synchronously |
| Input Impedance | 750kΩ |
| Input Coupling | AC |
| Sensor Drive Current | 4 mA to 24 V |
| A/D Converter | 24 bits delta-sigma ADC |
| Sampling Frequency | 51.2 Hz, 165 Hz, 512 Hz, 1289 Hz, 2560 Hz, 5120 Hz, 12.8 KHz, 25.6 KHz, 51.2 KHz |
| Dynamic Range | 114 dB |
| Signal Input Range | 0 V to 24 V |
| Weight | About 5.51 lb. (2.5 kg) |
| Ambient Temperature | -40 °F to 158 °F (-40 ℃ to 70 ℃) |
| Storage | -58 °F to 185 °F (-50 ℃ to 85 ℃), non-condensable |
