Features
- Support local data simulation;
- BTL, CE, IS09001 SGS certifications;
Support converting more than 200 protocols to BACnet, Modbus, MQTT, OPC UA, OPC XML-DA; -Easy to configure byX2View; - You can build SCADA, HMl, and alarming systems so that you can monitor and control the state of devices by smart phone, iPad or PC; Cloud Platform Integration work with WEB gateway;
- Support converting to BACnet server, Modbus server, MQTT/Cloud server;
- Support WeChat, E-Mail, Ding Talk alarm;
- Support user group management, configuration screen monitoring can set permissions;
- Support various forms of timing, event triggering, and provide a custom function;
- Support storing up to 200 historical points, save data every 5 minutes about a year;
- Built-in MySOL database;
- Support local data simulation;
- Map Storage can be customized;
- Support the timer, which can be used to start/stop the device at a fixed time or set values;
- Support remote monitoring the terminal devices by smart phone, iPad or PC;
- Support cloud configuration.
Technical Specifications
| Application | M2M IoT, M2M and IoT application |
| Interface | 2Ethernet ports,2 RS485 Serial ports |
| Chipset | ARM |
| Type | Ethernet Module |
| Power Consumption | 6W |
| Systems | LINUX |
| Installation | Guide rail type |
| Memory | 64M |
| Flash | 128M |
| Power Supply | 24V AC/DC |
| Support Protocols | 200+ |
| Ports | 2 Network Port, 4 RS485 Ports, 1 232 Serial Port |
| Humidity | 320% to 90% RH |
| Temperature | -4 °F to 158 °F (-20°C to 70°C) |
| Size | 5.79 in x 3.70 in x 1.38 in (14.7 cm x 9.4 cm x 3.5 cm) |
| Weight | 0.66 lbs (0.3 kg) |
