Features
- Supports the standard LoRaWAN protocol with global frequency band options
- Utilizes Semtech SX130X chips
- 8 Data Channels and 1 control channel, with full-duplex/half-duplex options
- Supports LoRaWAN IoT-vision, with built-in NetServer options
- Compatible with network servers such as Tencent Cloud, LinkWAN, TTN, Chirpstack, Amazon, etc.
- Supports IPv6 and Modbus TCP protocol
- Transmission range up to 15 kilometers
- IP67 Protection Rating
- Supports standard PoE (Power over Ethernet) power supply
- Supports for Class A/B/C
- Integrated WiFi/GPS/LTE/LoRa Antenna
- Certified with CE and FCC.
Technical Specifications
| Humidity | 5% to 95% |
| Max Transmission Power | 26 dbm |
| Power Consumption | 7 W |
| Installation | Wall-mounted or pole-mounted |
| CPU | Industrial grade cpu operating at 400MHZ |
| Memory | 64M DDR2 ram, 16M SPI flash |
| LoRa Data Rate | 292bp to 5.4kbps |
| Ethernet Communication Rate | 100Mbps |
| LTE Communication Rate | 50Mbps |
| Working Frequency | CN470MHz to 510MHz EU863 MHz to 870MHz US902 MHz to 928MHz AS920 MHz to 925MHz AU915 MHz to 928MHz KR920 MHz to 923MHz RU864 MHz to 870MHz IN865 MHz to 867MHz |
| Max Transmission Power | 26dbm |
| Rx Sensitivity | -142dbm@SF12 (half-duplex)/-138dBm@SF12 (full-duplex) |
| Channels | 8 Data channels, 1 control channel |
| Communication Interface | 1*LAN, 1*WAN，1*WIFI，1*LTE module |
| Operating Temperature | -40 °F to 176 °F (-40°C to 80°C) |
| Size | 11.34 in x 8.46 in x 2.32 in (28.8 cm x 21.5 cm x 5.9 cm) |
