Technical Specifications
| Product Type | LORA MODULE |
| Supplier Type | INDUSTRIAL |
| Communication Distance | 236,220.6 in (600,000 cm) |
| Wireless Management | WIFI Management and Upgrade |
| Local Storage | 32 G TF card |
| Communication Bandwidth | 125 kHz,250 kHz,500 kHz |
| Power Way | AC220, POE, Solar power |
| Communication Network | Star Topology |
| LoRaWAN Protocol | Class A, Class B, Class C |
| Working Frequency | EU433, CN470-510, CN779-787, EU863-870, US902-928, AU915-928, AS923, KR920-923 |
| Communication Distance (Outdoor) | 3.73 m (6 km) |
| Max TX Power | 25 ± 2 dBm |
| RX Sensitivity | LoRa: -140 dBm; Wi-Fi: -70 dBm |
| Communication Bandwidth | 125 kHz, 250 kHz, 500 kHz |
| Channels | 8 Upstream, 1 Downstream Channel |
| Data Communication | No Data Loss, No Relay Wireless Communication |
| Speed | Link Adaptive Speed |
| Work Mode | Supports Different Frequency and Same Frequency |
| Location | GPS, Beidou |
| Report to Server | 3G/4G, Wired Network |
| Wireless Management | Wi-Fi management and Upgrade |
| Local Storage | 32 GB TF Card |
| Antenna Interface | I-pex to N-type, External |
| LoRa Antenna | N-type Female, LoRa Fiberglass Antenna, 2 dBi Gain |
| 4G Antenna | N-type Female, 4G Fiberglass Antenna, 3 dBi Gain |
| Wi-Fi Antenna | N-type female, 2.4G Fiberglass Antenna, 3 dBi Gain |
| GPS Antenna | N-type female, GPS Fiberglass Antenna, 4 dBi Gain |
| Power Supply | AC220, POE, Solar Power |
| POE Support | Auto 10/100 Base-T, IEEE802.3af/IEEE802.3at |
| Power Consumption (Standby) | Average Current ≤140mA @12V |
| Power Consumption (Communication) | Transmit current ≤550mA @12V, Receive Current ≤420mA @12V |
| Working Temperature | -40°F to 185°F (-40 °C to 85 °C) |
| Storing Temperature Range | -40°F to 257°F (-40 °C to 125 °C) |
| Size | 11.40 in x 8.57 in x 4.53 in (28.96 cm x 21.78 cm x 11.51 cm) |
| Weight | 95.24 oz (2700 g) |
