Features
- Open-source hardware or software
- AT Commands to change parameters
- Micro SIM card slot for NB-IoT SIM
- 8500mAh Battery for long term use
Technical Specifications
| Module | Quectel BC 95-G |
| Protocols Supported | CoAP, UDP, MQTT |
| MCU | STM 32L072CZT6 |
| Flash Memory | 192 KB |
| SRAM | 20 KB |
| EEPROM | 6 KB |
| Clock Speed | 32 MHz |
| Supply Voltage | 1.8V to 3.6V |
| I or O Pin Voltage | +0.5 V |
| Power Consumption | 10 μA @ 3.3 V |
| Battery Type | Li or SOCI2 non-rechargeable battery |
| Battery Capacity | 8500 mAh |
| Self-Discharge | < 1 % per year @ 77 °F (25 °C) |
| Max Continuous Current | 500 mA |
| Max Boost Current | 2 A |
| Operating Temperature | -40 °F to +185 °F (-40 °C to +85 °C) |
