Features
- Multiple Power Supply Options
- High-Range Measurement Capability
- Durable Build Materials
- Precise Calibration Standards
Technical Specifications
| Power Supply | 12V DC 24V DC (optional) |
| Measuring Range | 0.01 to 1000 NTU |
| Material | SUS316L (Ordinary Version) Titanium Alloy (Seawater Version (optional) |
| Working Temp/Pressure | 32 °F to 113 °F (0 °C to 45 °C) / 0 MPa to 0.4 MPa ≤8.2 ft/s (2.5 m/s) (optional) |
| Output | Modbus RS485 4 mA to 20 mA, 0 V to 5 V DC (optional) |
| Calibration | Sample Calibration Slope Calibration (optional) |
| Dimensions | 10 in x 2.4 in (25.6 cm x 6 cm) |
| Accuracy | ±5% of measured value or ±0.1 NTU Max |
