Technical Specifications
| Measuring Range | 9.84 in to 393.7 in (25 cm to 1000 cm) |
| Resolution | ±(1 + S × 0.3%) cm |
| Dead Band | 9.84in (25 cm) |
| Detection Mode | Direct reflection type |
| Response Time | 0.9 s to 2.5 s |
| Beam Angle | 15° |
| Sensitivity | High |
| Output Signal | TTL signal, pulse width signal, differential signal |
| Connection Type | UART automatic, UART control, PWM, RS485 |
| Measuring Medium | Liquid |
| IP Rating | IP67 |
| Working Voltage | DC 3.3V to 5V |
| Power Consumption | ≤15 mA |
| MTTF | 26,000 hours |
| Signal Voltage | 3.0V |
| Housing Material | Plastic |
| Operating Temperature | 5°F to 140°F (-15°C to 60°C) |
| Storage Temperature | -13°F to 158°F (-25°C to 70°C) |
