Technical Specifications
| Spreading Factor | SF 7 to SF 12 |
| Frequency Band | 433/470/868/915/923 |
| Transmit Power | + 30 dBm max |
| Receiving Sensitivity | -135 dBm (at SF 10 at BW 125 KHz ) |
| Power Supply Interface | 9 V DC to 36 V DC (typical:12Vdc) |
| PoE Power Supply | 38 V DC to 57 V DC (typical:48Vdc) |
| Average Operating Power Consumption | 1 W |
| Configuration Interface | BLE |
| LoRa Communication | Drive SX1302, 8 channels upstream, 1 channel downstream |
| Data Return | Ethernet / Wi-Fi |
| Operating Temperature | -10 °F to 158 °F (-20 ℃ to 70 ℃) |
| Dimension | 4.33 in x 1.38 in (11 cm x 3.5 cm) |
