Features
- Rotating at 360 degrees
- Long service life
- High accuracy
- Distant measurement
- Strong anti-interference ability
- It can be used outdoors and, in the sun
Technical Specifications
| Use | Sensing radar |
| Mounting Type | TTL |
| Type | LiDar sensor laser |
| Theory | Acoustic sensing |
| Output | N/A |
| Distance | 0.32 ft to 131.23 ft (0.1 m to 40 m) |
| Laser Wavelength | 905 nm ± 15 nm |
| Ranging Accuracy | ±30 mm |
| Range Resolution | mm |
| Echo Mode | Single pulse |
| Measure Frequency | 16.2 KHz |
| Measure Angle | 360° |
| Angle Resolution | 0.23° @10 Hz, 0.34° @15 Hz |
| Scan Frequency | 7 Hz to 15 Hz |
| Echo Intensity | 0 to 254 |
| Drive | Built-in DC, brushless motor |
| Communication Interface | UART 3.3 V |
| Optical Interference Resistance | >80000 LX |
| Supply Voltage | DC 5.1 V ± 0.2 V |
| Power Dissipation | ≤3 W |
| Waterproof | IP5X |
| Output Mode | N/A |
| Input | N/A |
| Programmable Alert Area | N/A |
| Alert Area Support Shape | N/A |
| Working Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Size | 2.16 in × 2.16 in × 2 in (5.5 cm × 5.5 cm × 5.1 cm) |
| Weight | 3.8 oz (108 g) |
