Features
- High range ratio
- Self-diagnostic function
- Photoelectric interface
- Bidirectional measurement
- Patented flow measurement with smart error detection.
Technical Specifications
| Accumulated Flow Resolution | 0.0001 m3 (Daily) 0.001 L (Inspection） |
| Instantaneous Rate Resolution | 0.001 m3 per h (Daily) 0.001 m3 per h (Inspection） |
| Battery Life | 8 years |
| LCD Digits | 9 |
| Temperature Class | T30, T50 |
| Pressure Class | MAP16 |
| Pressure Loss Class | △p 25 |
| Ambient Class | Class A, Class B |
| Waterproof Class | IP68 |
| Accuracy Class | 2 |
| EMC Class | E1, E2 |
| Flow Section Sensitivity Class | U5 or D3 |
| Installation | Horizontal or Vertical |
| Reverse Flow | Reverse Flow Measurable |
| Interface & Communication | Infrared, MBUS or RS-485, Pulse or LoRa or LoRaWAN |
| Power | Multiple Power Supply Methods: Built-in Battery Power Supply (default) and DC 24 V External Power Supply or MBUS Power Supply |
| Q3(Q max per permanent) | 2.500 m3 per h |
| Q4(Q overload) | 3.125 m3 per h |
| Q2(Q transitional) | 0.016 m3 per h |
| Q1(Q min) | 0.010 m3 per h |
| Start Flow Rate | 0.002 m3 per h |
