Features
- Ethernet port
- TCP/UDP modes
- MQTT support
- Web config
- Remote upgrade
- Custom JS plug-ins
- Node-Red support
Technical Specifications
| Data Rate | 0.292 to 21.875 Kbps |
| Sensitivity | -137 dBm |
| RF Output Power | 13 dBm (JPN) or 14 dBm (EU) or 17 dBm (China) or 20 dBm (USA, TWN) |
| Network Communication | Ethernet |
| Ethernet | 10/100 Mbps fast Ethernet |
| M2M Protocol | MQTT |
| Packet Forwarder | Compatible with ANNWS.01.2.1.W.SYS gateway to server |
| Network Interface | Support DHCP, Static IP and DHCP server |
| Administration Portal | Support Chrome and Firefox |
| ANT Impedance | For LoRa: 50 ohm |
| Operation Temp. | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temp. | -4 °F to 176 °F (-20 °C to 80 °C) |
| Dimension | 5.28 in x 3.35 in x 1.69 in (134 mm x 85 mm x 43 mm) |
