Features
- 3 In 1 function
- Wi-Fi and Ethernet supported
- LoRaWAN Class A and Class C protocols
Technical Specifications
| Main Control Chip | ESP32 MCU |
| Wi-Fi and Ethernet Support | Yes |
| Maximum Output Power | 27 dBm ± 2 dBm |
| Power Supply Voltage | 5 V |
| LoRaWAN Protocol Support | Class A, Class C |
| Working Bands | Full band coverage corresponding to the working frequency option |
| Antenna Output | Supports external antenna |
| LoRa Baseband Chip | SX1308 |
| LoRa RF Chip | SX1250 |
| Operating Temperature Range | – 40 °F to 176 °F (- 40 °C to 80 °C) |
| Dimensions | 3.04 in x 2.7 in x 0.9 in (77.3 mm x 70 mm x 23 mm) |
