Features
- Positioning and navigation system
- LoRaWAN connectivity
Technical Specifications
| Chipset | SX1276 |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2B |
| LoRa Fastest Communication Frequency | 5 s |
| LoRa Sensitivity | – 139dBm at SF12, BW 125 kHz, 434 MHz or 470 MHz – 137 dBm at SF12, BW 125 kHz, 868 MHz or 915 MHz |
| Transmission Capacity | 100 beacon messages can be Received within 1s, maximum of 15 beacon Messages can be sent in one package |
| Geo-Fence | Supported |
| Encryption | AES128 |
| Power Supply Mode | 5 V or 1 A |
| Connect To Power Source | Yes |
| Operating Humidity | 5 % RH to 95 % RH |
| Operating Temperature | – 40 °F to 185 °F (- 40 °C to 85 °C) |
| Storage Temperature | – 58 °F to 185 °F (- 50 °C to 85 °C) |
| Dimension | 4.72 in x 4.72 in x 1.2 in (120 mm x 120 mm x 31 mm) |
