Features
- LoRaWAN 1.0.3 Class A
- Ultra-low power consumption
- Bands: CN470/EU433/KR920/US915/EU868/AS923/AU915/IN865
- Door Open/Close detect
- Door open/close statistics
- Datalog Feature,
- Open Alarm Feature Support Bluetooth v5.1 and LoRaWAN remote configure Support wireless
- OTA update firmware Uplink on periodically Downlink to change configure
- 8500mAh Battery for long term use
- Wall Mountable Outdoor Use Applications: Wireless Alarm and Security Systems Home and Building Automation Industrial Monitoring and Control
Technical Specifications
| Supply Voltage | Built-in 8500mAh Li-SOCI2 battery, 2.5V to 3.6V |
| Frequency Range, Band 1 (HF) | 862 MHz to 1020 MHz |
| Max +22 DBm Constant RF Output Vs RX Sensitivity | down to -139 dBm |
| Battery Type | Li/SOCI2 un-chargeable battery |
| Capacity | 8500 mAh |
| Max Continuously Current | 130 mA |
| Max Boost Current | 2 A, 1 second |
| Sleep Mode | 5 uA, 3.3 V |
| LoRa Transmit Mode | 125 mA, 20d Bm, 82 mA, 14 dBm |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
