| Network Standard |
Supports 4G, 5G, and one WAN port |
| Power Supply |
9-24V DC / 2A |
| Interface |
1 RS232 or 485 or 1 WAN or 2 LAN |
| Supported Bands |
433 / 470 / 868 / 915 / 923 MHz |
| Netcom Compatibility |
Fully compatible with 2G, 3G, 4G, 5G networks (Telecommunications, Mobile, China Unicom) |
| Cable Network Backup |
Ensures stable data transmission with backup between networks |
| Internet Access |
Supports Wi-Fi, 4G, Ethernet, and simultaneous multi-network online access |
| Wi-Fi Functionality |
AP, STA, Repeater modes |
| Interfaces |
4-way WAN port, RS232 serial port, RS485 serial port, USB, and 4 AD/IO interfaces |
| Wireless Extensions |
Optional: LoRa, Zigbee |
| Network Switching |
Intelligent multi-network switching with data storage and resume on reconnection |
| Protocols Supported |
Transparent transmission, MODBUS RTU switch TCP, MQTT |
| MODBUS Device Support |
Supports polling MODBUS devices, simplifying SCADA commands |
| Communication Module |
Industrial-grade high-speed 4G module with a 32-bit high-end processor |
| Downstream Wireless Options |
Optional: LoRa, Zigbee, Bluetooth |
| Industrial Design |
Metal case, stable 24/7 operation under harsh industrial environments and strong interference conditions |
| Size |
4.53 in x 5.16 in x 2.17 in (115 mm x 131 mm x 55 mm) |
