Features
- Weatherproof IP66-rated enclosure
- Supports LoRaWAN US915MHz frequency
- Provides stable power via 5V/2A input
- Enhanced security for IoT data
- High durability in harsh environments
- Low power consumption for efficiency
Technical Specifications
| Humidity | 0 % RH To 100 % RH |
| Power Consumption | 3.6 W |
| Power Supply | DC 12 V / 2 A |
| Certification | CE, FCC, Rohs |
| Installation Method | Wall Or Pole Mounting |
| Enclosure Material | PC |
| UV Resistance | Anti-Aging (From Rain/Sun Exposure): UL746C F1 |
| IP Rating | IP66 |
| Memory | 8GB Emmc |
| CPU | TI AM3358 Cortex-A8 1ghz System |
| Grounding | Reserved 1 Screw Hole For GND |
| LED Indicator | Indicating Network Condition (Online/ Offline) |
| Indicating Network Condition (Online/ Offline) | 0-4dbi Gain / Linear Polarization / Omnidirectional / SMA-J Connector |
| Lora Antenna | 2.5dbi Gain / Vertical Polarization / Omni-Directional / SMA-J Connector |
| UMTS Features | Support 3GPP R8 DC-HSDPA, HSPA+, HSDPA, HSUPA And WCDMADC-HSDPA: Max 42Mbps (DL) HSUPA: Max 5.76Mbps (UL)WCDMA: Max 384Kbps (DL), Max 384Kbps (UL) |
| Ethernet | 100Mbps FE (RJ-45) |
| Lora Power Output | 25dbm |
| Channel Plan | 902 Mhz To 928mhz |
| 4G Features | Support Non-CA Cat 4 FDD And TDDLTE-FDD: Max 150Mbps (DL), Max 50Mbps (UL)LTE-TDD: Max 130Mbps (DL), Max 30Mbps (UL) |
| Operating Temperature | -40 °F To 158 °F (-40°C To 70°C) |
| Device Dimensions | 10.08 In × 6.30 In × 3.19 In (25.6 Cm X 16 Cm X 8.1 Cm) |
| Weight | 27.41 Oz (777 G) |
