Features
- BLE module
- LoRaWAN connectivity
- Positioning and navigation system
Technical Specifications
| Chipset | SX1276 |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2 B |
| LoRaWAN Band | US 915 MHz, AU 915 MHz, EU 868 MHz, EU 433 MHz AS 920 MHz to 923 MHz, AS 923 MHz to 925 MHz, RU 864 MHz, ID 920 MHz, KR 920 MHz, IN 865 MHz, KZ 865 MHz, CLAA, CN 470 MHz |
| LoRa Maximum RF Power | 20 dBm |
| LoRa Sensitivity | – 139 dBm at SF12, BW 125 kHz, 434 MHz or 470 MHz – 137 dBm at SF12, BW 125 kHz, 868 MHz or 915 MHz |
| Access Quantity | > 500 in one LoRa gateway |
| Data Rate (Bps) | 300 to 30 K |
| Beacon Access Quantity | 100 beacon messages can be Received within 1 s, maximum of 15 beacon messages at one single LoRa communication |
| Peak Current | Max. 140 mA in transmit mode |
| Ingress Protection | IP66 |
| Positioning Precision | 9.8 ft (3 m) |
| Encryption | AES128, X509 |
| Standby Time | 2552 days Bluetooth receiving windows: 3 s Positioning interval: 5 min (300 s) Average data size: around 12 beacons (5.5 bytes per beacon, 2624 ft/s (800 ms) beacon advertise interval) Use commands to change the period of position report to save power |
| Battery | 38,000 mAh Lithium thionyl chloride battery |
| Operating Temperature | – 40 °F to 185 °F (- 40 °C to 85 °C) |
| Weight | 5.29 oz (150 g) |
| Dimension | 6.3 in x 6.3 in x 2.2 in (160 mm x 160 mm x 55 mm) |
