Technical Specifications
| Chipset | SX1276 |
| Application | Positioning and Navigation |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2B |
| LoRa Fastest Communication Frequency | 5 s |
| LoRa Sensitivity | -139 dBm @ SF12, BW 125 kHz, 434 MHz or 470 MHz -137 dBm @ SF12, BW 125 kHz, 868 MHz or 915 MHz |
| Transmission Capacity | 100 beacon messages can be received within 1 s, Maximum of 15 beacon messages can be sent in one package |
| Geo-Fence | Supported |
| Encryption | AES128 |
| Power Supply Mode | 5 V/1 A |
| Connect to Power Source | Yes |
| Certification | CE, FCC, RCM |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Storage Temperature | -58 °F to 185 °F (-50 °C to 85 °C) |
| Operating Humidity | 5% to 95% |
| Dimension | 4.72 in × 4.72 in × 1.22 in (12 cm × 12 cm × 3.1 cm) |
