Technical Specifications
| Chipset | SX1301+SX1255 |
| Application | Smart Cities And Communities |
| Supplier Type | OEM |
| Supply Ability | 100 Piece/Pieces Per Month |
| Lorawan Protocol | Class A/Class B/Class C |
| Memory | 8GB Flash, 512MB DDR4 RAM |
| Processor | Quad-Core 1.5 GHz, 64-Bit ARM Cortex-A53 |
| Frequency | EU433/CN490/IN865/EU868/US915/AS923MHz |
| Communication Distance | 6.84 Miles (11 Km) |
| Backhaul Connectivity | ETH |
| Spreading Factor | SF7 To SF12 |
| Frequency Band | 433/470/868/915/923 |
| Transmit Power | +27dBm Max |
| Receiving Sensitivity | -136dBm (@SF10@BW125KHz) |
| Routing Channel | 8Rx, 1Tx |
| Power Supply Interface | 9V To 36Vdc (Typical: 12Vdc) |
| Poe Power Supply | 38V To 57Vdc (Typical: 48Vdc) |
| Average Operating Power Consumption | 3.6 W |
| Configuration Interface | Ethernet/Wi-Fi |
| Configuration Method | WEB (Gateway Management) |
| Lora Communication | Drive SX1301, 8 Channels Upstream, 1 Channel Downstream, Support Beacon |
| Data Return | Compatible With Packet Forwarder Communication Protocol (UDP) |
| USB Interface | USB2.0x4, Used To Expand Peripherals |
| USB Interface | USB To Serial Port, Manufacturer-Specific |
| Ethernet Interface | (1000 cm/10000 cm) Ethernet, Support Standard PoE Power Supply |
| Input Port | 2 Wet Node Inputs, 9V To 36V |
| Output Port | 2 Relay Outputs, Resistive Load 5A |
| Lora Antenna Interface | SMA Outer Screw Inner Needle |
| Product Size | 0.0079 In (0.02 Cm) |
