Technical Specifications
| Chipset | SX1301 + SX1255 |
| Application | Smart cities and communities |
| LoRaWAN Protocol | Class A or Class B or Class C |
| Memory | 8 GB Flash, 512 MB DDR4 RAM |
| Processor | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Frequency | EU433 MHz, CN490 MHz, IN865 MHz, EU868 MHz, US915 MHz, AS923 MHz |
| Communication Distance | 6.83 mile (11 km) |
| Backhaul Connectivity | ETH |
| Spreading Factor | SF7 to SF12 |
| Frequency Band | 433, 470, 868, 915, 923 |
| Transmit Power | +27 dBm max |
| Receiving Sensitivity | -136 dBm (@SF10 @BW 125 kHz) |
| Routing Channel | 8 RX, 1 TX |
| Power Supply Interface | 9 V to 36 V DC (typical: 12 V DC) |
| PoE Power Supply | 38 V DC to 57 V DC (typical: 48 V DC) |
| Average Operating Power Consumption | 3.6 W |
| Configuration Interface | Ethernet or Wi-Fi |
| Configuration Method | WEB (Gateway management) |
| LoRa Communication | Drive SX1301, 8 channels upstream, 1 channel downstream, support Beacon |
| Data Return | Compatible with packet forwarder communication protocol (UDP) |
