Overview
Specimen Track’s LoRaWAN Smart ID Badge with Indoor & Outdoor Real-Time Tracking is a smart ID badge based on LoRaWAN network transmission. It supports GPS and Beidou dual-mode outdoor positioning and Bluetooth 4.0 indoor positioning. This device provides positioning accuracy of 10 meters outdoor and 3 to 5 meters indoor. Through intelligent trackers, beacons, LoRaWAN gateways, and the Web platform or app, it enables real-time tracking of staff and visitors, helping enterprises and institutions manage personnel efficiently and ensure safe production.
Features
- Indoor & Outdoor real-time positioning
- Built-in NFC, RFID
- SOS in emergency: Press the positioning button to relocate your position and send to the platform
- External personnel management
- OEM your own Log
Technical Specifications
| Application | Indoor location to asset tracking |
| Protocol | LoRaWAN Class A |
| Frequency | AU915 to EU868 |
| NFC | Supported |
| Uplink Frequency | Customized |
| Protection | IP66 |
| Buttons | 1 power button to 1 re-positioning button |
| RFID | Optional, detect range 1 to 6 m |
| Communication Range | 3,280 ft (1 km) in dense environment, 9,843 to 16,404 ft (3 to 5 km) LOS |
| Tx Power | 14 dBm |
| Frequency Band | 470 to 510 MHz, EU868 MHz and US915 MHz optional |
| Positioning | Outdoor: support GPS to Beidou dual mode; Indoor: active positioning (BLE) |
| Positioning Accuracy | 32.8 ft (10 m) outdoor, 9.8 to 16.4 ft (3 to 5 m) indoor |
| Battery | Built-in 900 mAh rechargeable Li battery |
| Battery Life | More than 40 h at 5-minute GNSS positioning interval |
| Supply Voltage | 5 V |
| Operating Temperature | -4 to 140 °F (-20 to 60 °C) |
| Size | 3.41 in X 2.17 in X 0.31 in (86.5 mm X 55 mm X 8 mm) |
