Overview
Specimen Track’s LoRaWAN smart outdoor asset tracker with high accuracy GNSS is an exceptional outdoor tracker that utilizes GNSS and Wi-Fi AP MAC Address Scanning to provide highly accurate positioning data. Additionally, it has tilt and temperature sensors for more extensive data collection and application in various scenarios. The device is designed with IP67 and IK09 ratings to cater to different environments. This device collaborates with LoRaWAN® gateway and mainstream LoRaWAN network servers with low power consumption, allowing it to operate for over 15 years with twice-daily reports. By integrating with LoRaWAN® gateway and IoT Cloud solution, users can remotely and visually manage all sensor data.
Features
- High-accurate GNSS positioning
- Cooperate with Wi-Fi positioning
- Support geofencing for targeted messaging
- Up to 15 years battery life
- Industrial and anti-theft design
Technical Specifications
| Chipset | SX1302 |
| Protocol | LoRaWAN |
| Frequency | CN 470 MHz, IN 865 MHz, RU 864 MHz, EU 868 MHz, US 915 MHz, AU 915 MHz, KR 920 MHz, AS 923 MHz, 921 MHz, 922 MHz, 923 MHz, and 924 MHz |
| Tx Power | 16 dBm (868 MHz) or 20 dBm (915 MHz) or 19 dBm (470 MHz) |
| Sensitivity | – 137 dBm at 300 bps |
| Mode | OTAA or ABP Class A |
| Position Accuracy (CEP) | 16 ft (5.0 m) (direct line of sight) |
| Resolution | Longitude or latitude: 0.0001 Altitude: 3 ft (1 m) |
| Time to First Fix | Cold start: 37 s average Hot start: 1 s average |
| Sensitivity | Tracking: – 167 dBm Reacquisition: – 160 dBm Cold start: – 148 dBm Hot start: – 159 dBm |
| Wi-Fi Positioning | Indoor asset location using Wi-Fi access point scanning (device does not connect to Wi-Fi) |
| Wi-Fi Parameters | BSSID, RSSI |
| Wi-Fi Standard | 802.11 b or g or n 2.4 GHz |
| Status | Normal or tilt |
| Power On and Off | NFC, power button (internal) |
| Configuration | NFC, Bluetooth® 5.3 |
| Power Supply | 4 x 2700 mAh ER14505 Li-SOCl2 replaceable batteries |
| Battery Life | Twice daily location updates: > 15 years Tenth daily location updates: > 8 years Hourly location updates: > 4 years |
| Material and Colour | PC and black |
| Ingress Protection | IP67 |
| Impact Protection | IK09 |
| Installation | Wall screw mounting, 3M tape mounting, cable-tie mounting |
| Relative Humidity | 0 % to 95 % (non-condensing) |
| Temperature Resolution | 32.18 °F (0.1 °C) |
| Temperature Range | – 40 °F to 257 °F (- 40 °C to 125 °C) |
| Operating Temperature | – 22 °F to 158 °F (- 30 °C to 70 °C) |
| Product Weight | 7.13 oz (202 g) (batteries are included) |
| Dimension | 4.33 in x 2.76 in x 1.18 in (110 mm x 70 mm x 30 mm) |
