Features
- Real Time 4G and SMS Data Upload
- Integrated 16-bit MCU & Siemens 4G and Ethernet Module
- Programmable data input type & alert high/low
- Programmable Data Upload Interval & Logging Interval
- Easy setup via USB port using PC software
- Remote setup over 4G mobile network
- RS485 port supports data capturing in Modbus protocol
- Supports Dynamic Domain Name or Fixed IP, and UDP/TCP protocol data transmission
- Flexible AC/DC power with internal battery backup
Technical Specifications
| Application | GPS, 2G, 3G, 4G Module |
| Supplier Type | New |
| Form Factor | Mini PCIe |
| Frequency Bands LTE-FDD | B1/B3/B5/B7/B8/B20 (SIM7600E-H), B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28/B66 (SIM7600G-H) |
| Frequency Bands LTE-TDD | B38/B40/B41 (SIM7600E-H), B34/B38/B39/B40/B41 (SIM7600G-H) |
| Frequency Bands WCDMA | B38/B40/B41 (SIM7600E-H), B1/B2/B4/B5/B6/B8/B19 (SIM7600G-H) |
| Frequency Bands GSM | 900/1800 MHz (SIM7600E-H), 850/900/1800/1900 MHz (SIM7600G-H) |
| GNSS Support | Yes |
| Supply Voltage | 3.0 to 3.6 V |
| Power Consumption LTE | 2.3 mA |
| Power Consumption WCDMA, DRX=9 | 3.3 mA |
| Power Consumption GSM, BS_PA_MFRMS=2 | 2.8 mA |
| LTE Data Transfer Rate | 150 Mbps DL / 50 Mbps UL |
| HSPA+ Data Transfer Rate | 42 Mbps DL / 5.76 Mbps UL |
| WCDMA Data Transfer Rate | 384 Kbps DL / 384 Kbps UL |
| GPRS/EDGE Data Transfer Rate | 236.8 Kbps DL / 236.8 Kbps UL |
| Operating Temperature | -40 °C to +85 °C (-40 °F to +185 °F) |
| Product Weight | 3.53 oz (0.100 kg) |
| Size | 2.00in x 1.22in x 0.21 in (50.8mm x 31mm x 5.35 mm) |
