Overview
GOTAek proximity lidar sensor is using the dtof ranging principle, compared with the laser radar based on triangulation ranging, the ranging range is wider and is not easily affected by external ambient light. The data sampling rate is up to 18 kHz, providing more data support for detection decision at the same time. The laser power received at the fixed point in unit time is less than 1mw, which conforms to the class1 laser safety standard.
Features
- High quality point cloud
- Compact structure
- Ultra small volume
- High data sampling rate
- Realistic view of smooth glass
- Built in brushless motor
Technical Specifications
| Scanning Principle | Mechanical Rotation |
| Range | 0 in to 1574.8 in (0 m to 40 m) |
| Horizontal FOV | 270° |
| Distance Resolution | 0.39 in (1 cm) |
| Range Accuracy | 0.78 in (2 cm) |
| Data Sample Rate | 45kHz |
| Laser Class | Class 1 Eye Safe |
| Wavelength | 940 nm |
| Environmental Protection | IP65 |
| Operating Voltage | 9 V to 36 V |
| Power Consumption | ≤2W |
| Storage Temperature | -40 °F to 167 °F (-40°C to 75 °C） |
| Operating Temperature | -13 °F to 140 °F (-25 °C to 60 °C） |
| Weight | 0.35 lb (160 g) |
| Dimension | 2.36 in x 2.36 in x 3.14 in (60 mm x 60 mm x 80 mm) |
