Features
- Real Time Ethernet and Data Upload
- Integrated 16 bit MCU & Ethernet Module
- Programmable data input type & alert hi or low
- Programmable data upload interval & logging interval
- Easy setup via USB port by PC software
- Remote setup by Ethernet
- RS485 port support data capturing in Modbus protocol
- Support Dynamic Domain Name or Fixed IP, and UDP or TCP protocol data transmission
- Flexible AC or DC power with internal battery backup
Technical Specifications
| Chipset | Modbus |
| Application | Industrial, network transmission |
| Certification | CE FCC RoHS |
| Protocol | Ethernet TCP or UDP |
| Interface | RS232 or RS485 |
| Color | Black |
| Power Input | 9 V to 15 V DC |
| Display Type | Analog and digital |
| Function | Data transmission |
| Signal Type | 4 mA to 20 mA or 0 V to 5 V DC |
| Data Upload | On schedule or manual request or alarm triggered |
| Internal Data Record | Average 30000 records (4 MB) |
| Alarm Trigger | Digital alarm or AD level high or low or power loss |
| Digital Channel | Alarm dry contact |
| Data Logging Interval | Programmable (1 minutes to 60 minutes) |
| Pulse Channel | On or off switching |
| Data Transmission | Ethernet |
| Output | 5V DC |
| Data Upload Interval | Programmable (5 s to 24 hours) |
| Industrial Protocol | Modbus |
| Modbus Device Port | RS485 |
| Modbus Device Support | 16 data registers |
| Temperature Channel | -67 °F to 257 °F (-55 °C to 125 °C) |
