Technical Specifications
| Processor | MT7628, DDR2 RAM 128 MB |
| Wi-Fi Characteristic | Frequency: 2.4 GHz (802.11b/g/n), RX Sensitivity: -95 dBm (Min), TX Power: 20 dBm (Max), Channels: 1-13 |
| LoRa Chip | Semtech SX1302 + 2 x SX1250 |
| Number of Channels | 8/16 |
| Receiving Sensitivity | -139 dBm @125 KHz or SF12 |
| TX Power | 27 dBm (Max) |
| Frequency Compatibility | EU433, CN470, EU868, US915, AS923, AU915, IN865, KR920, RU864 |
| Mobile Network Support | Quectel EC25-E, EC25-AFXD, EC200M-CN |
| Power Supply | 12V DC; PoE (IEEE 802.3 af), 40-57V DC |
| Ethernet | RJ45 (10M/100M) |
| LoRa Wan Working Mode | Supports Class A/B/C |
| Consol Interface | USB Type-C |
| Antenna Interface | LoRa, LTE, Wi-Fi, and GPS: N Type Connector |
| Ingress Protection | IP67 |
| Material | Aluminum |
| Dimensions | 7.28 in x 7.28 in x 1.69 in (18.5 cm x 18.5 cm x 4.3 cm) |
| Weight | 6.61 lbs (3 kg) |
