Multi Dimensional Force Sensor with Mechanical Decoupling – Specimen Track

The Multi-Dimensional Force Sensor with Mechanical Decoupling offers precise force measurement, ideal for IoT applications in various industries.

SKU: STRMFS-303 Category:

Technical Specifications

Rated output ≈ 1.0 mV/V
Zero balance ± 2% F.S.
Non-linearity 0.08% F.S.
Hysteresis 0.03% F.S.
Repeatability 0.03% F.S.
Interference error 1% F.S.
Creep (30 min) 0.05% F.S.
Temp. effect on output 0.05% F.S.
Insulation ≥ 5000 MΩ (100 VDC)
Recommended excitation 5 to 12 V
Maximum excitation 15 V
Safe overload 150% F.S.
Ultimate overload 300% F.S.
