Features
- LoRa supports 8RX 1TX channels
- Support 2.4G WiFi
- 100M base-T Ethernet supporting PoE
- Support Ethernet, WiFi or LTE uplink multi-link backup
- OpenWRT software program that supports LoRaWAN and network configuration
- Built-in radiator for heat dissipation
- Access to private or public (TTN) LoRa network server
- Support TF card storage method
- Suitable for use at indoor ambient temperature
- Support optional LTE 4G function support
Technical Specifications
| Information Content | Data |
| Condition | New |
| Processor | MT7628, DDR2RAM 128MB |
| Power Consumption | 12W |
| Console | RJ45 (RS232) |
| Support Network | Ethernet |
| Power Supply | DC 12V to 1A |
| Ethernet | RJ45 (10 M or 100 M) |
| Processor | MT 7628, DDR 2 RAM 128MB |
| Wifi Function | Frequency 2.400 GHz to 2.4835 GHz (802.11b or g or n), RX sensitivity -95dBm (minimum), TX power 20dBm (maximum), Operating channel 2.4GHz 1 to 13 |
| LoRa Function | SX1301 Mini PCIe card 8 lanes, RX sensitivity: -142dBm (minimum), TX power 27dBm (maximum), Frequency EU433, CN470, EU868, US915, AS923, AU915, KR920, IN865 |
| Mobile Cellular Network | Support optional Quectel EG95-E or EG95-NA LTE CAT 4 network, not supported by default |
