Features
- Integrated NB-IoT module compatibility
- Compatible with M2M applications
- Low energy consumption design
- Wide-area wireless connectivity support
- Stable and reliable network performance
- Extended battery life duration
Technical Specifications
| Operating Voltage | 2.9 V to 3.7 V (DC) |
| Average Operating Current | At sensor detection: ≤15, When NB-IoT data is reported: ≤ 110 mA |
| Standby Current | ≤10 µA |
| Battery Capacity | 13000 mAh (3.6V disposable lithium sub batteries) |
| Battery Life | 5 Years (Based on 2 reports per day and relatively good signal conditions) |
| Testing Cycle | 5 Minutes (Can be set) |
| Sensor Interface | UART, RS485 optional |
| Plane Range | 25 cm to 200 cm (Supporting DYP-A13-V1.0 module parameters, S is the distance to the measured object) |
| Measuring Accuracy | ±(1+0.3% x S) cm |
| Distance Resolution | 1 mm |
| Measuring Angle | Φ7.5 cm × 100 cm white PVC@100cm: 20° |
| Temperature Detection Range | -67 °F to 257 °F ( -55 °C to 125 °C ) |
| Temperature Detection Accuracy | ±3.6 °F ( ±2 °C) |
| Inclination Detection Range | 0 to 180° |
| Wireless Network Standard | NB-IoT, CAT-M1* |
| Wireless Band | NB-IoT: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85, CAT-M1*: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85 |
| Network Protocol | TCP/UDP/Http Push /CoAP*/MQTT* |
| Positioning Function | GPS/Galileo (Optional GLONASS/BDS/QZSS) |
| Positioning Accuracy | 3 m (In open conditions) |
| Waterproof Grade | IP67 |
| Operating Temperature | -4 °F to 158 °F ( -20 °C to 70 °C ) |
| Main Body Size | 3.9 in x 2.6 in x 1.9 in (100 mm x 68 mm x 50 mm) |
