Features
- Wireless detection of parking spot occupancy.
- High accuracy: radar and magnetic technology combination.
- IP68 for indoor and outdoor use (CE and FCC).
- LoRaWAN communication protocol.
- Over the air setup.
- Easy installation (on surface).
- Almost zero maintenance needed.
Technical Specifications
| Battery Type | Lithium Battery 3.6 V and 19 Ah |
| Detection Technology | Magnetic Field Variation Detection |
| Communication Protocol | Lorawan |
| Mounting Type | Surface Mounted |
| Power Source | Built-In Rechargeable and Replaceable Battery |
| Battery Life | Up to 5 Years to 10 Years |
| Enclosure Material | Industrial-Grade, Weather-Resistant Polymer |
| Color | Black and Grey |
| Power Consumption | Ultra Low Power Operation |
| Energy-Saving Mode | Adaptive Sleep Mode to Extend Battery Life |
| Detection Method | Magnetic Sensor-Based Vehicle Detection |
| Operating Voltage | 3.0 V to 3.6 V DC |
| Detection Accuracy | 98 % |
| Response Time | 1 Second |
| False Alarm Rate | 2 % |
| Sensitivity | Configurable Sensitivity Levels |
| Modulation | Lora Spread Spectrum |
| Transmission Power | +14 Dbm to +22 Dbm |
| Receiving Sensitivity | -137 Dbm |
| Data Transmission Interval | Configurable |
| Adaptive Data Rate | Supported |
| Ip Rating | IP 67 and IP 68 |
| Impact Resistance | IK 08 or Higher |
| Communication Distance | 2 Km to 10 Km |
| Uv Resistance | Yes |
| Data Encryption | AES-128 End-to-End Encryption |
| Storage Temperature | -40 °F to 185 °F (40 °C to +85 °C) |
| Dimension | 7.09 In X 7.09 In X 2.36 In (18 Cm X 18 Cm X 6 Cm) |
| Weight | 0.44 Lbs to 1.10 Lbs (200 Kg to 500 Kg) |
