Features
- High-accuracy measurement
- 4G NB-IoT wireless connectivity
- Wide temperature range operation
- Long battery life with 19Ah capacity
- Customizable pressure and temperature range
Technical Specifications
| Power Supply | 3.6 V DC, 19 Ah battery |
| Measurement Signal | Pressure signal or PT100 temp signal |
| Maximum Emission Current | ≤ 200 mA |
| Transmit Power | 23 dBm ±2 dB |
| Receiving Sensitivity | -115 dBm |
| Accuracy | 0.5% FS |
| Pressure Range | -14.50 PSI to 10,153 PSI (-100 KPa to 70 MPa) |
| Liquid Level Range | 656.17 ft (200 m) |
| Temperature Range | -328 °F to 1,562 °F (-200 °C to 850 °C) |
| Operating Temperature | -40 °F to 176 °F (-40 °C to 80 °C) |
| Weight | 1.76 lb (0.8 kg) |
| Dimensions | 10.63 in x 5.12 in x 7.87 in (27 cm x 13 cm x 20 cm) |
