Features
- Wireless output, no complex wiring needed
- Micro power design, standby current 10 uA
- Device parameters modifiable remotely
- Magnetic switch design for easy routine operations
Technical Specifications
| Material | ABS stainless steel |
| Overload | 200 % FS (<10MPa) 150 % FS (>25MPa) |
| Connection | M20 X 1.5 (can be customized) |
| Accuracy | ± 0.5 % ±0.2 % ±0.1 % ± 0.075 % |
| Stability | ±0.3% FS/Year |
| Supply Voltage | 3.6VDC Lithium Battery 17000mAh |
| Communication Method | NB-IoT/LoRa/4G |
| Communication Protocol | COAP/MQTT/Lorawan/CLAA/IEEE802.15.4 |
| Communication Interval | 60 seconds |
| IP Rating | IP 67 |
| Medium | Non-Corrosive Fluids |
| Insulation | >100 MΩ @ 250 VDC |
| Working Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Storage Temperature | -40 °F to 257 °F (-40 °C to 125 °C) |
