| Communication |
RS485(Baud Rate is Adjustable), Pulse, Opt. NB-IoT, GPRS |
| Display |
9 Digits LCD Display, can Display Cumulative Flow, Instantaneous Flow, Flow, Pressure, Temperature, Error Alarm, Flow Direction etc. at The Same Time |
| RS485 |
Default Baud Rate 9600bps (opt. 2400 bps, 4800 bps), Modbus-RTU |
| Connection |
Flanges According to EN1092-1 (others Customized) |
| Flow Profile Sensitivity Class |
A Full Bore (U5/D3) B 20% Reduced Bore (U3/D0) C Reduced Bore (U0/D0) |
| Data Storage |
Store the Data, Including Day, Month and Year for 10 years. The Data can be Permanently Saved Even Powered off |
| Max. Working Pressure |
1.6 Mpa |
| Temperature Class |
T30, T50, T70, T90(Default T30) |
| Accuracy Class |
ISO 4064, Accuracy Class 2 |
| Body Material |
Stainless Steel SS304(Opt. SS316L) |
| Battery Life |
15 years (Consumption ≤0.5mW) |
| Protection Class |
IP68 |
| Pressure Loss |
ΔP10, ΔP16, ΔP25(Based on Different Dynamic Flow |
| Climatic And Mechanical Environment |
Class O |
| Electromagnetic Class |
E2 |
| Frequency |
1 to 4 times/second |
| Environmental Temperature |
-40 ℉ to 158 ℉ (-40 ℃ to 70 ℃), ≤100%RH |
