Overview
OPM Fiber Optic Tester with 26 dB Dynamic Range & 4.3 in Touchscreen adopts 4.3 in (10.92 cm) capacitive touch screens. It integrates 12 functions, such as auto OTDR, expert OTDR, event map, OPM, RJ 45 cable tracker, and computer level file management to meet various test requirements in different occasions. This product supports a maximum dynamic range of 26 dB, 8 GB of memory, and can store more than 200,000 curves. It provides 4000 mAh high-density polymer lithium batteries, intelligent power-saving management, measuring time of more than 8 hrs, and support power supply and charging from power banks. It measures the length, loss, connection quality, and other parameters of optical fibers. This product provides FTTX, secondary backbone network engineering construction, maintenance, and emergency repair tests, as well as in the production measurement of optical fibers and cables.
Technical Specifications
| Wavelength | 650 nm |
| Power | 10 mW |
| Range | 7.45 mi (12 km) |
| Connector | FC or UPC |
| Resolution | 0.01 dB |
| Working Wavelength | 1310 nm or 1550 nm or 1625 nm |
| Accuracy | 0.5 dB |
| Operating Temperature | -0.4° F to 95° F (-18° C to 35° C) |
| Magnification | 400x |
| View Of Field | 0.40 nm x 0.31 nm |
| Sensor | 1 or 3 in 2 million of pixel |
| Output Power | -25 dBm to 0 dBm |
| USB Port | 1.1 port or 2.0 port |
| Dimension | 9.25 in x 3.74 in x 1.18 in (235 mm x 95 mm x 30 mm) |
| Weight | 0.33 lb (150 g) |
