Technical Specifications
| Humidity | 95% |
| Communication Network | Start topology |
| LoRaWAN Protocol | Class A, class B, class C |
| Working Frequency | EU433,CN470-510,CN779-787 |
| Communication Distance | 16,404.2 ft (6km) |
| Local Storage | 32G TF card |
| Communication Bandwidth | 125kHz,250kHz,500kHz |
| RX Sensitivity | Max -140dbm @LoRa ; -70dbm @WIFI |
| Communication Bandwidth | 125kHz,250kHz,500kHz |
| Channels | 8 upstream channel,1 downstream channel |
| Speed | Link adaptive speed |
| Work Mode | Support different frequency and same frequency |
| Report to Server | 3G/4G, Wired network |
| Wireless Management | WIFI management and upgrade |
| Local Storage | 32G TF card |
| LoRa Antenna, Interface | N-type female, LoRa fibre-glass antenna ,2dBi gain |
| 4G Antenn,Interface | N-type female, 4G fibre-glass antenna,3dBi gain |
| WIFI Antenna,Interface | N-type female,2.4G fibre-glass antenna,3dBi gain |
| GPS Antenna, Interface | -type female,GPS fibre-glass antenna,4dBi gain |
| Power Way | AC220,POE,Solar power |
| POE Standard | IEEE802.3af/IEEE802.3at |
| Average Current | ≤140mA@12V |
| Transmit Current | ≤550mA@12V |
| Receive Current | ≤420mA@12V |
| Operating Temperature | -40 °F to 185 °F (-40 ℃ to 85 ℃) |
| Storing Temperature Range | -40 °F to 257 °F (-40 ℃ to 125 ℃) |
| Size | 11.4 in × 8.56 in × 4.53 in (28.94 cm × 21.75 cm × 11.5 cm) |
| Weight | 95.24 oz (2700 g) |
