Features
- Open source
- Web GUI management
- Semtech UDP support
- LoRaWAN station
- Cellular failover
- Direct ABP comm
- Packet filtering
- LED indicator
- Built-in GPS
- External antenna
Technical Specifications
| OS | Open-Source Embedded Linux system |
| Management | Web GUI, SSH via LAN or WiFi |
| Packet Forwarder | Support Semtech UDP packet forwarder |
| LoRaWAN Station | Support LoRaWAN Station Connection |
| Cellular Failover | Optional |
| Communication | Direct Communication to LoRaWAN ABP Node |
| Packet Filtering | LoRaWAN packet filtering |
| Indicators | Far-seeing LED indicator |
| GPS Module | Built-in GPS module for location & timing |
| Antenna | External fiberglass antenna |
| Provisioning | Auto-Provision |
| Monitoring | Remote Monitoring |
| Power Over Ethernet | 802.3af PoE |
| Protection | IP65, Lightning Protection |
| Power Consumption | 12V, 300-500mA |
| Sensitivity | Up to -140 dBm with SX1250 Tx/Rx front-end |
| Interferer Rejection | 70 dB CW at 1 MHz offset |
| SNR Operation | Able to operate with negative SNR, CCR up to 9 dB |
| Demodulators | Emulates 49 x LoRa demodulators and 1 x (G)FSK demodulator |
| Radio Front-End | Dual digital TX & RX interfaces |
| Demodulation Paths | 10 programmable parallel paths |
| Data Rate Adaptation | Dynamic data-rate (DDR) adaptation |
| Antenna Diversity | True antenna diversity or simultaneous dual-band operation |
| Ethernet Ports | 10M/100M RJ45 Ports x 1 |
| WiFi | 802.11 b/g/n |
| Wireless Protocol | LoRaWAN |
| Power Input | 12 V DC to 24 V DC, 2 A |
| PoE Port | IEEE 802.3af compliant (DC 37 V to 57 V) |
| USB | USB 2.0 host connector x 1 |
| PCI-E | Mini-PCI E connector x 1 |
| LoRa Baseband | SX1302 + 2 x SX1250 |
