Features
- High power
- Quad-core CPU
- LoRaWAN compatible
- IP67 weatherproof
- Multi-connection
- Embedded server
- Large capacity
Technical Specifications
| Chipset | Quad-Core |
| Processor | 1.5 GHz, 64-bit ARM Cortex-A53 |
| Power Supply | 802.3 af PoE Input, 12 VDC with M12 Connector |
| Working Current | Typical 3.6 W, Max 4.8 W |
| Radio Chip | SX1302 |
| Frequency | AU915 MHz |
| Tx Power | 27 dBm Max |
| Protocol | V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C |
| Ports | 1 x 10/100/1000 Mbps RJ45 (PoE PD supported), auto MDI/MDIX |
| Standard | IEEE 802.11 b/g/n, 2.4 GHz |
| VPN Tunnel | DMVPN or IPsec or OpenVPN or PPTP or L2TP or GRE |
| ANT | 2 x Antenna connector |
| ETH | 1 x 10/100/1000 Mbps with PoE in |
| RST | Reset to factory settings |
| DC Power | M12 connector |
| SIM Slot | 1 x mini-SIM (2FF) |
| Micro SD | SD card slot |
