Features
- Multiple Interfaces
- PoE Support
- Wide Temperature Range
- High Sensitivity
- Customizable ROM
- Low Power Consumption
- 3 SMA Antenna Ports
Technical Specifications
| CPU | ROCKCHIP Quad-core Cortex-A55 64-bit, 1.8 GHz processor |
| RAM | 2G DDR4 |
| ROM | 32G eMMC 5.1 (customizable to 8 or 16 or 64 or 128G) |
| LoRa Baseband | SX1303 + SX1250 chipset |
| LoRa RX Sensitivity | -125 dBm @125KHz/SF7, -139 dBm @125KHz or SF12 |
| Wi-Fi (Optional) | IEEE 802.11 b or g or n |
| Operating System | Linux (4.19.219 Kernel, aarch 64), Debian 10 pre-loaded |
| Interfaces | DC Input, UART debug, ETH, SIM slot, SMA antenna sockets (x3) |
| Ethernet | 100 or 1000 M |
| Max Receiving Sensitivity | -139 dBm @ SF12, 125 KHz |
| Power Supply | 4.5 V to 17 V |
| LoRa TX Power | Up to 26±1 dBm |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Dimension | 6.49 in x 4.92 in x 2.05 in (16.5 cmx 12.5 cm x 5.2 cm) |
