Overview
Specimen Track PDA 1D/2D Barcode Scanner offers Wi-Fi, Bluetooth, 4G (FDD/TDD-LTE), phone, GPS, and an 8MP rear camera. Additional features include 1D/2D barcode scanning, NFC, and a 2MP front camera. The Safe droid OS (Android 10.0) ensures smooth operation. Its ergonomic design, wrist strap, and 5000mAh battery ensure mobility and reliable power. The pogo pin interface and optional charging cradle add convenience, while its rugged, water-proof IP66 design is ideal for industrial use. Standard shipping is through DHL, with other options for emergencies.
Technical Specifications
| Frequency | 13.56MHz |
| OS | Android |
| Protocol | Support ISO14443A/B, 15693 agreement |
| Performance | Octa core CPU Cortex-A53 Quad core 64-bit 2.0 GHz high performance processor RAM+ROM2GB+16GB Supports up to 4GB+64G System Android 10.0 |
| Data Communication | WLAN Dual frequency 2.4GHz/5GHz, support IEEE 802 a/b/g/n/ac protocol WWAN 2G: GSM (Mobile/Unicom), CDMA (Telecom) 3G: WCDMA (Unicom), CDMA2000 (Telecom), TD-SCDMA (Mobile) 4G: FDD: B1 or B3 or B4 or B7 or B8 or B12 or B20 TDD: B38/B39/B40/B41 Bluetooth Support BT 5.0 Transmission distance 5-10 meters GNSS Support Gps, Galileo, Glonass, Beidou |
| Physical parameter | Dimensions 201.8mm×72mm×25.6mm Weight <<>500g (Depends on device function configuration) Display 4.0″, 480×800 resolution TP Supports multi-touch Supported gloves and wet hands Battery capacity Rechargeable polymer battery (3.8V5000MAh) Standby time >350 hours Working time > 12 hours Support fast charge, removable battery Charging time <<> 3H, (Use the standard source adapter and data cable) |
| Memory Capacity | 256MB |
| CPU Type | ARM |
| Bluetooth | Support Bluetooth 5.0+BLE |
| Scanner | 1d or 2D Optional |
| Specification | 17.64 ounces. (500g) |
| Dimensions | 17.64 ounces. (500g) |
| Internet Connection | GPRS |
| Camera | 8 MP Camera for rear camera, 2MP front camera |
| Waterproof and Protection Grade | IP66 |
| Waterproof and Protection Grade | 4 inch |
| Dimensions | 4 in × 1.01 in (201.8 mm x 72 mm x 25.6 mm) |
| User Environment | Operating temperature -20ºC – 55ºC Storage temperature -40ºC – 70ºC Environment humidity 5%RH–95%RH (no condensation) Drop specification Temperature range, 6 sides can withstand a height of 1.2 meters 30 impacts of falling to the marble floor Sealing IP66 |
