| Measurement Range (Temperature) |
-22 °F to 1652 °F (-30 °C to 900 °C) |
| Temperature Accuracy |
± 1°C |
| Acceleration Frequency Range |
5 Hz to 2 kHz |
| Amplitude Range (Acceleration) |
± 16 g peak |
| Accuracy (Acceleration) |
± 5% (160 Hz) Z / X / Y axis |
| Communication Technology |
LoRaWAN, Bluetooth 5.0 |
| LoRaWAN Frequency Range |
470 to 510 MHz |
| Wireless Range (LoRaWAN) |
2.5 km |
| Wireless Range (Bluetooth) |
2.4 GHz ISM band |
| Battery Type |
Replaceable C 3.6V lithium sub battery |
| Battery Life |
3 years |
| IP Protection |
IP68 waterproof and dustproof |
| Explosion-Proof Rating |
ExiaIICT4 Zone 0 IIC gas environment |
| Operating Temperature Range |
-40 °F to 158 °F (-40 °C to 70 °C) |
| Weight |
8.05 oz (228 g) |
| Dimensions (Height x Diameter) |
3.35 in x 1.69 in (85 mm x 43 mm) |
| Material |
304 stainless steel, reinforced PC |
| Fixing Hole Size |
M6 x 1 mm x 0.28 in (7 mm) |
| Mechanical Resistance |
1 meter drop resistance onto concrete |
| Output Type |
Digital signal |
| Amplifier Type |
IDT |
| Voltage – Supply |
5V |
| Current – Supply |
0.3 mA |
| Current – Supply (Max) |
0.5 mA |
| Mounting Type |
DIP |
| Number of Axes |
3 axes |
| Sensing Unit |
MEMS |
| Data Acquisition Interval |
20 minute index |
| Output Mode |
Total value, effective value |
| Measuring Range (Temperature) |
-40 °F to 248 °F (-40 °C to 120 °C) |
| Bluetooth Frequency Range |
2.4 GHz ISM band |
| Bluetooth Power |
2 dBm |
| LORA Frequency Range |
470 to 510 MHz |
| Working Temperature |
-40 °F to 158 °F (-40 °C to 70 °C) |
| Corrosion Resistance |
Stainless steel body, solution resistant PC |
| Explosion Proof Safety |
ExiaIICT4 Zone 0 IIC gas environment |
| Security |
Micro power short-range radio equipment |
