Features
- MPPT solar charge controller
- 12V or 24V system voltage
- 15A maximum charge current
- Supports infrared and wireless remote control
- IP68 waterproof rating
- Works continuously for 24 hours
Technical Specifications
| System Voltage | 12V or 24V |
| Maximum Charge Current | 15A |
| Maximum Solar Input Voltage | ≤ 60V |
| Maximum Load Power | 80W at 12V or 160W at 24V |
| Static Power Consumption | 6mA at 12V; 4mA at 24V (R type) 18mA at 12V; 13mA at 24V (W type) |
| Controller Type | MPPT |
| Remote Control Type | Infrared (R type) 2.4G Wireless (W type) |
| IP Rating | IP68 |
| Work Time | 24 hours |
| Maximum PV Power | 120W |
| Maximum PV Voltage | 24V |
| Temperature Range | 14 °F to 122 °F (-10 °C to 50 °C) |
| Weight | 1.12 lb (510 g) |
| Dimensions | 5.6 in x 3.2 in x 1.0 in (14.2 cm x 8.2 cm x 2.4 cm) |
