Technical Specifications
| Nominal Diameter | Range Ratio (Q3/Q1) | Permanent Flow Rate Q3 | Transitional Flow Rate Q2 | Minimum Flow Rate Q1 | Overloaded Flow Rate | |
| DN 50 | 160 | 896.99 ft3/h (25.40 m3/h) | (0.250 m3/h) | (0.156 m3/h) | (31.25 m3/h) | |
| DN 80 | 200 | 1412.59 ft3/h (40 m3/h) | 11.3 ft3/h (0.320 m3/h) | 0.706 ft3/h (0.020 m3/h) | 1765.73 ft3/h (50 m3/h) | |
| DN 100 | 200 | 2224.82 ft3/h (63 m3/h) | 17.65 ft3/h (0.500 m3/h) | 11.124 ft3/h (0.315 m3/h) | 2781.03 ft3/h (78.75 m3/h) | |
| DN 125 | 200 | 3531.47 ft3/h (100 m3/h) | 28.25 ft3/h (0.800 m3/h) | 17.65 ft3/h (0.500 m3/h) | 4414.33 ft3/h (125 m3/h) | |
| DN 150 | 200 | 5650.35 ft3/h (160 m3/h) | 44.14 ft3/h (1.250 m3/h) | 28.25 ft3/h (0.800 m3/h) | 7062.93 ft3/h (200 m3/h) | |
| DN 200 | 200 | 8828.67 ft3/h (250 m3/h) | 70.62 ft3/h (2.000 m3/h) | 44.14 ft3/h (1.25 m3/h) | 11035.833 ft3/h (312.5 m3/h) | |
| DN 250 | 200 | 14125.9 ft3/h (400 m3/h) | 113.007 ft3/h (3.200 m3/h) | 70.62 ft3/h (2.000 m3/h) | 17657.3 ft3/h (500 m3/h) | |
| DN 300 | 200 | 22248.2 ft3/h (630 m3/h) | 176.573 ft3/h (5.000 m3/h) | 111.241 ft3/h (3.150 m3/h) | 27817.363 ft3/h (787.7 m3/h) | |
| DN 350 | 200 | 35314.7 ft3/h (1000 m3/h) | 282.517 ft3/h (8.000 m3/h) | 176.573 ft3/h (5.000 m3/h) | 44143.33 ft3/h (1250 m3/h) | |
| Type | Ultrasonic meters, prepaid water meters | |||||
| Material | Iron, steel | |||||
| Type | Ultrasonic water meter | |||||
| Communication Mode | MBUS, ImPulse, LoRa, GPRS, NB IoT | |||||
| Nominal Diameter | DN15, DN20 | |||||
| Diameter | DN50 to DN350 | |||||
| Accuracy | Class 2 B | |||||
| Standard | ISO 4064 class 2 B | |||||
| Maximum Working Pressure | 1.0 MPa or 1.6 MPa | |||||
| Minimum Flow Rate | 0.706 ft3/h (0.020 m3/h), 5.509 ft3/h (0.156 m3/h) | |||||
| EMC Grade | E1 | |||||
| Climatic and Mechanical Environmental Grades | B | |||||
| Range Ratio | 160, 200 | |||||
| Protection Grade | IP68 | |||||
| Temperature Grade | T50 | |||||
