Features
- WiFi & NB-IoT support
- Accurate Class 1 energy measurement
- LCD digital display for monitoring
- RS485 Modbus communication
- Operates in extreme temperatures
Technical Specifications
| Phase | Single Phase |
| Measuring Energy Range | 5 to 60 A |
| Output Voltage | 220 V |
| Accuracy Class | Class 1 |
| Operating Temperature | -13 °F to 140 °F (-25 °C to 60 °C) |
| Storage Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Display Type | LCD Digital Display |
| Communication | RS485 Modbus or NB-IoT |
| Frequency | 50 Hz |
| Relative Humidity | ≤95% |
| Starting Current | 0.004 Ib |
| Weight | 0.88 lb (0.4 kg) |
| Dimensions | 1.37 in x 3.53 in x 2.71 in (3.48 cm x 8.98 cm x 6.9 cm) |
