| Applicable Industries |
Farms |
| Video outgoing-inspection |
Provided |
| Machinery Test Report |
Provided |
| Core Components |
Engine |
| Key Selling Points |
Solar power |
| Usage |
Agriculture |
| Type |
Irrigation system |
| Material |
Plastic |
| Application |
Agriculture garden farm irrigation |
| Battery |
18650 lithium battery (wide temperature), battery capacity: 2000 mAh 3.7 V, four pcs |
| Solar Panel |
Polysilicon 6 V, 5 W |
| Solar Panel Port |
Stable voltage and current device inside, can connect 5 V to 30 V DC power |
| Flowmeter (external) |
Max flow rate: 10 m/s |
| Min flow rate: 0.3 m/s |
| Working pressure: 5 kg/cm2 |
| Valve Torque |
≤60 N.m |
| Max Power |
3.8 W at communication (max. power at full emission) |
| 25 W at locked motor (overcurrent protection inside device) |
| Advantage |
One valve control, two water flow |
| Control Mode |
4G or LoRaWAN |
| Global frequency |
LTE FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B66 |
| Valve open adjustment |
Ratio adjustment |
| Remote upgrade |
OTA |
| Power Supply |
Solar energy + Lithium battery |
| Protection grade |
IP67 |
| Valve Diameter |
DN32 to DN50 |
| Flow meter |
Ultrasonic flow meter (optional) |
| Media Temperature |
32 °F to 158 °F (0 °C to 70 °C) |
| Working temperature |
-4 °F to 158 °F (-20 °C to 70 °C) |
| Diameter |
31.49 in (80 cm) |
| Solar Panel Size |
7.67 in × 7.67 in (19.5 cm × 19.5 cm) |
| Weight |
17.63 lb(8 kg) |
