Technical Specifications
| Wavelength | 1310 nm & 1470 nm to 1610 nm |
| Output Power | -9 dBm to -3 dBm or -5 dBm to 0dBm |
| Optic Fiber | 50 or 125 u multimode, 62.5 or 125 u multimode, 9 or 125 u single mode |
| Rx Sensitivity | -25 dBm |
| Optical Connector | FC, ST, SC, LC (optional) |
| Distance | 0.31 mi (500 m) or 12.43 mi (20 km) or 24.86 mi (40 km) or 37.28 mi (60 km) or 49.71 mi (80 km) |
| Number of Channels | 8 |
| Input Connector XLR (female) | XLR (female) |
| Output Connector | XLR (male) |
| Input / Output Impedance | 10 K Ohm |
| Input Capacitance (LINE inputs) | 10 pF |
| Max Input or Output Voltage | 3.0 V p-p |
| Frequency Response | 10 Hz to 24 kHz at ± 3 dB |
| Sample Rates | From 48 kHz |
| SNR | > 80 dB |
| Power Adapter | AC 90 V to 240 V |
| Power Consumption | < 8 W |
| Installation | 19’’ 1U rack-mount chassis |
| Shipping Weight (include Transmitter & Receiver) | 15.43234 lb (7 kg) |
| Environmental Temperatures | Operating Temperature: -4 °F to 167 °F (-20 °C to +75 °C) Storage Temperature: -40 °F to 185 °F (-40 °C to +85 °C) |
| Relative Humidity | 0% to 95% (non-condensing) |
| MTBF | >100,000 hrs |
