Overview
The Specimen Track datalink plus is an advanced standard all-optical GE switch with 48 optical downlink ports and four 10 GE uplink ports. These switches are powered by Versatile Routing Platform (VRP) and provide support for enhanced Layer 3 capabilities, streamlined Operations and Maintenance (O&M), adaptable Ethernet networking, and mature Internet Protocol version 6 (IPv6) features. They are versatile, serving as access or aggregation switches for campus networks and as access switches for Metropolitan Area Networks (MANs) or data center networks.
Features
- All-optical GE switches with 48 downlink ports
- Support Layer 3, IPv6, flexible networking
- Suitable for campus, MAN, or data center
Technical Specification
| Fixed Ports | 48 x GE SFP ports, 4 x 10 GE SFP+ ports |
| Flexible Upgrade | Not supported |
| MAC Features | IEEE 802.1d compliance Automatic MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses |
| VLAN Features | 4094 VLANs Guest VLAN and voice VLAN GVRP MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping |
| IP Routing | Static route, RIP v1 / v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+ |
| Interoperability | VBST (compatible with PVST / PVST+ / RPVST) LNP (similar to DTP) VCMP (similar to VTP) |
