Technical Specifications
| Thermal Fan | Fan less |
| Copper Port | 10 10 or 100 BASE-TX MDI or MDIX Ports |
| PoE Injector Port | 16-port with 802.3 at or af PoE injector function with Port-1 to Port-16 |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 4 Gbps / non-blocking |
| Switch Throughput at 64 bytes | 1.48 Mpps at 64 bytes |
| MAC Address Table | 16 K entries, automatic source address learning and aging |
| Maximum Frame Size | 1522 bytes |
| Flow Control | IEEE 802.3x pause frame for full duplexBack pressure for half-duplex |
| LED System | Power (Green) |
| 10/100BASE-TX RJ45 interfaces | 10 Mbps or 100 Mbps LNK or ACT (Green) |
| PoE interfaces | PoE-in-Use (Red or Blue) |
| DIP Switch | Selectable operation mode-Standard, VLAN, Extend |
| Enclosure | Metal |
| Power Requirements | 52 V DC, 3.8 A |
| Power Consumption/Dissipation | System On: Max. 2.4 wattsEthernet Full Loading: Max. 5 watts PoE Full Loading: Max. 120 watts |
| ESD Protection | Contact discharge of 4 KV DC, Air discharge of 6 KV DC |
| Power over Ethernet PoE Standard | IEEE 802.3 af Power over Ethernet / PSEIEEE 802.3 at Power over Ethernet Plus / PSE |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port max. 30 watts |
| Power Pin Assignment | (1 / 2) + (3 / 6) – |
| PoE Power Budget | 120 watts |
| Max. Number of Class 2 PDs | 8 |
| Max. Number of Class 3 PDs | 8 |
| Max. Number of Class 4 PDs | 4 |
| Regulatory Compliance FCC Part | Class A, CE |
| Standards Compliance IEEE Standards | IEEE Standards: IEEE 802.3 uIEEE 802.3 x IEEE 802.3 af IEEE 802.3 at IEEE 802.3 az Energy Efficient Ethernet (EEE) |
| Operating Temperature | Temperature: 14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature | Temperature: 14 °F to 158 °F (-10 °C to 70 °C) |
| Humidity | 5% RH to 95% RH (non-condensing) |
| Dimensions | 8.67 in x 6.3 in x 1.6 in (22cm)×(16cm)×(4cm) |
