Overview
Specimen Track gigabit ethernet fiber converter can be used anywhere in the network to integrate newer technology with existing equipment to support new applications, technologies and future growth. Instead of costly, across-the-board upgrades, media converters can extend the productive life of the existing cabling as well as the active equipment.
Features
- Built-in high-performance kernel, Broadcast storm control
- Flow control, CRC error checking
- 1000 Base-FX fiber-optic transmission standard
- Can be interconnected with other products
- Auto-negotiation function
- The UTP port supports the connection of MDI or MDI-X auto crossover
- Single mode Fiber: the max distance up to 37.2 mi (60 km)
- Supporting the max 1536-byte Ethernet packet
Technical Specifications
| Data Rate | 1000 Mbit/s |
| Wavelength | Depends on SFP module |
| Transmission Rate | Self-adaptive 10 Mbps or 100 Mbps or 1000 Mbps |
| Connector | Depends on SFP module |
| Fiber Type | Depends on SFP module |
| Distance | Depends on SFP module |
| Power Supply | AC 220 V, DC 5 V or 1 A |
| Working Temperature | 32 ℉ to 122 ℉ (0 °C to 50 °C) |
| Storage Temperature | -40 ℉ to 158 ℉ (-40 °C to 70 °C) |
