Overview
Specimen Track hub indoor LoRa gateway acts as the base station of the LoRaWAN network allowing bidirectional communication between end-user nodes. As a programmable IoT Gateway designed for the IoT Gateway Developer, it provides various connections to the cloud, including Wi-Fi and Ethernet.
Features
- Global Frequency Plans
- Multiple protocol Gateway
- Multiple Backhaul connectivities
- High Capacity
Technical Specifications
| CPU | MT 7628 AN, MIPS 24 KEc, 580 MHz |
| Power supply | 5 V / 2 A Adapter |
| Lora Concentrator Engine | Semtech SX 1302 |
| OS | Linux |
| RAM | 128 MB |
| Flash | 32 MB |
| Encryption key | ECC 608 A / B |
| Wireless Protocol | Wi-Fi 2.4 G / 5 G,Lora |
| Working Temperature | -10 °F to 140 °F (-10 ℃ to 60 ℃) |
| Ethernet | RJ 45 |
| Chip | ECC 608 A / B |
| Size | 14.17 in x 10.43 in x 1.18 in (96 mm x 94.5 mm x 31 mm) |
